Ausverkauf Z-FDB 1-2

• 50mm² input, 2x 20mm² outputs, for optimal current flow.
• Smoked polycarbonate housing, sturdy, scratch-resistant, durable.
• Knurled screws secure contact, effectively prevent short circuits.
• More technical details

Audio System Z-FDB 1-2 is a Fuse Holder with a 1x up to 50 mm² input and two 2x up to 20 mm² outputs. The housing is made of Smoked Polycarbonate and is sturdy as well as scratch-resistant. Knurled screws support the contact of the connected cables. The cable connection is recessed. Secured with Mini-ANL fuses; Mini-ANL fuses are available optionally. The dimensions are 117 x 41 x 42 mm.

Features

• Fuse Holder
• 1x up to 50 mm² input
• 2x up to 20 mm² output
• Smoked Polycarbonate housing, sturdy and scratch-resistant
• Knurled screws for better contact of the connected cables
• Recessed cable connection
• Secured with Mini-ANL fuses
• Mini-ANL fuses available optionally

Technical Data

• Dimensions: 117 x 41 x 42 mm
• Recommended fuse values 1.5 mm²: optimal 10 A, maximum 15 A
• Recommended fuse values 2.5 mm²: optimal 20 A, maximum 25 A
• Recommended fuse values 4.0 mm²: optimal 25 A, maximum 30 A
• Recommended fuse values 6.0 mm²: optimal 35 A, maximum 40 A
• Recommended fuse values 10 mm²: optimal 50 A, maximum 60 A
• Recommended fuse values 16 mm²: optimal 70 A, maximum 80 A
• Recommended fuse values 20 mm²: optimal 90 A, maximum 100 A
• Recommended fuse values 25 mm²: optimal 100 A, maximum 125 A
• Recommended fuse values 35 mm²: optimal 125 A, maximum 150 A
• Recommended fuse values 50 mm²: optimal 160 A, maximum 200 A
• Recommended fuse values 70 mm²: optimal 200 A, maximum 250 A
• Recommended fuse values 95 mm²: optimal 250 A, maximum 300 A
