Begrenztes Angebot HMD8 DSP

• Power per channel: 130 watts at 2 Ω, 85 watts at 4 Ω.
• Minimum load impedance 2 Ω, distortion only 0.06% at 4 Ω.
• Bandwidth from 10Hz to 22kHz, signal-to-noise ratio 105 dBA.
• More technical details

HMD8 DSP is an 8-Channel Amplifier from Hertz with integrated DSP and PC software interface. The output power is 85 Watts x 8 at 4 Ohms, 130 Watts x 8 at 2 Ohms, and 260 Watts x 4 bridged at 4 Ohms (RMS @ 28.8 VDC, 1% THD). The minimum load impedance is 2 Ohms in 8-channel operation and 4 Ohms in bridged 4-channel operation. The amplifier operates with a bandwidth of 10 Hz to 22 kHz, a signal-to-noise ratio of 100 dBA (Master input) or 105 dBA (optical input), and a total harmonic distortion of 0.06% at 1 kHz, 4 Ohms, and 70% rated power. The damping factor is >110 at 1 kHz, 4 Ohms, and 2 VRMS. The input sensitivities are 0.6 – 6 VRMS (Pre-In) and 2.2 – 22 VRMS (Speaker-In). Control of up to three zones is possible. Robust construction with corrosion-protected circuit board.

Features

• 8-Channel Amplifier
• Integrated DSP with PC software interface
• Control of up to three zones
• Corrosion-protected circuit board and robust construction
• RMS power @ 28.8 VDC, 1% THD: 85 Watts x 8 at 4 Ohms
• RMS power @ 28.8 VDC, 1% THD: 130 Watts x 8 at 2 Ohms
• RMS power (Bridge 1/2; 3/4; 5/6; 7/8) @ 28.8 VDC, 1% THD: 260 Watts x 4 at 4 Ohms
• Minimum load impedance: 2 Ohms (8 channels)
• Minimum load impedance: 4 Ohms (4 channels bridged)
• Filter types: All-pass, High-pass, Low-pass, Band-pass
• Filter models/Slopes: Butterworth (6–60 dB/Oct.), Linkwitz-Riley (12–60 dB/Oct.), Bessel (6–60 dB/Oct.), Chebyshev (6–60 dB/Oct.), Quasi-linear QLP-phase (6, 12 dB/Oct.)
• Crossover frequency: 20 Hz – 20000 Hz
• Phase control: 0° – 180°
• Output EQ: Graphic and parametric, 10 parametric poles (Peaking, High Shelf, Low Shelf, Notch, All Pass), ±12 dB, Q 0.5 – 16.0; 10 graphic poles
• Presets: Rotary switch for 7 installation presets
• Memory: 2; additionally, 3 parametric poles (Peaking, High Shelf, Low Shelf) per memory, ±12 dB, Q 0.5 – 16.0

Technical Specifications

• Operating supply voltage: 11 – 15 VDC (2 x 30 A)
• Power supply: 6.5 – 17 V
• Idle current: 1.6 A
• Power consumption when off: 1.7 mA
• Consumption @ 14.4 VDC, 2 Ohms, max. music power: 55 A
• Remote-IN voltage: 6 – 15 VDC (1 mA)
• Remote-OUT voltage: 4 – 15 VDC (150 mA)
• Distortion (THD) @ 1 kHz, 4 Ohms, 70% rated power: 0.06 %
• Damping factor @ 1 kHz, 4 Ohms, 2 VRMS: >110
• Bandwidth @ -1.5 dB: 10 Hz – 22 kHz
• Signal-to-noise ratio (A-weighted @ 1 V input), Master input: 100 dBA
• Signal-to-noise ratio (A-weighted @ 1 V input), optical input: 105 dBA
• Input sensitivity Pre-In: 0.6 – 6 VRMS
• Input sensitivity Speaker-In: 2.2 – 22 VRMS
• Time alignment distance: 0 – 1371.6 mm
• Delay for time alignment: 0 – 15 ms
• Step for time adjustment: 1 cm
• Max. size (W x H x D): 238 x 49.5 x 155 mm
• Weight: 1.98 kg
