Bestpreis Ultimax II UMII18-22

Bestpreis Ultimax II UMII18-22

Ursprünglicher Preis war: 423,04 €Aktueller Preis ist: 169,22 €.

Sichere Zahlung Karte, PayPal und geschützter Checkout
Kostenloser Versand ab 29,99 € Schnelle Lieferung in ganz Deutschland
Schneller Support Hilfe bei Bestellungen und Versand
Artikelnummer: SK0001449-DE20260613-175157 Kategorie:
  • 1200 watts of power, 2+2 ohm impedance, 76 mm voice coil.
  • Resonant frequency at 22 Hz, sensitivity 90.7 dB, frequency up to 500 Hz.
  • Total excursion over 50.8 mm, BL 19.2 Tm, cone area 1184 cm².
  • More technical details

The Dayton Audio Ultimax II UMII18-22 is an 18 inch (46 cm) Subwoofer with dual voice coils 2 + 2 Ohm. The 76 mm voice coil, a diaphragm made of Nomex honeycomb composite with fiberglass reinforcement, and an aluminum basket form the foundation. A large rubber surround and dual 203 mm spiders allow for a total excursion of over 50.8 mm with an Xmax of 28 mm. The specifications include a sensitivity of 90.7 dB (2.83 V/1 m), a resonance frequency of 22 Hz, and a frequency response of 20–500 Hz. Other parameters are a BL of 19.2 Tm, Sd of 1184 cm², Vd of 3315 cm³, and a Vas of 248.2 liters. The dimensions include an outer diameter of 470 mm, a cutout diameter of 426 mm, and a total depth of 258 mm; mounting is done via 8 holes with a diameter of 6.5 mm.

Features

  • 18 inch (46 cm) Subwoofer
  • Diaphragm made of Nomex honeycomb composite, fiberglass reinforced
  • Large rubber surround
  • Dual 203 mm spiders
  • Two 2-Ohm copper voice coils, dual-layer (DVC 2 + 2 Ohm)
  • Voice coil diameter 76 mm
  • Aluminum basket
  • Total excursion of the diaphragm over 50.8 mm

Technical Specifications

  • Series: Ultimax II DVC
  • Type: Subwoofer
  • Nominal diameter: 18 inch
  • Power handling (QMW): 1,200 Watts
  • Impedance: 2 + 2 Ohm
  • Sensitivity (2.83 V/1 m): 90.7 dB
  • Frequency response: 20–500 Hz
  • Voice coil diameter: 76 mm
  • DC resistance (Re): 4.2 Ohm
  • Voice coil inductance (Le): 1.15 mH
  • Resonance frequency (Fs): 22 Hz
  • Qms: 2.53
  • Qes: 0.67
  • Qts: 0.53
  • Moving mass (Mms): 420 g
  • Diaphragm area (Sd): 1184 cm²
  • Displacement volume (Vd): 3315 cm³
  • Force factor (BL): 19.2 Tm
  • Equivalent volume (Vas): 248.2 liters
  • Maximum excursion (Xmax): 28 mm
  • Basket/frame material: Aluminum
  • Outer diameter: 470 mm
  • Total depth: 258 mm
  • Cutout diameter: 426 mm
  • Mounting holes: 8
  • Diameter of mounting hole: 6.5 mm
