Billig Perfect Match Iridium GZIB 3.250SPL

• The subwoofer system offers 1500W RMS, with 1.4 Ohm impedance.
• The amplifier delivers 2000W at 1 Ohm, with a stable aluminum construction.
• The capacitor has 2.0 Farads, ESR of 0.0015 Ohms, LED voltage display.
• More technical details

Discover the Perfect Match Iridium GZIB 3.250SPL, a Subwoofer Complete Set available in the Masori Shop. This set offers triple bass power through three GZIW 10XSPL subwoofers housed in a robust bass reflex enclosure for a maximum excursion of 34 mm. The DD Audio SS2000 amplifier with 2000 watts RMS power and a heavy aluminum housing ensures optimal heat dissipation. A 2.0 Farad Hifonics capacitor effectively prevents voltage drops. The specialized wiring with 35mm² Stage2 OFC cable guarantees interference-free signal transmission. An M8 ring set allows for corrosion-protected integration into the power supply.

Features

• Triple bass power: The Ground Zero bass reflex enclosure combines three GZIW 10XSPL subwoofers for enormous air displacement and 34 mm maximum excursion.

• High-performance drive: The DD Audio SS2000 amplifier delivers a solid 2000 watts at 1 Ohm and guarantees optimal heat dissipation with its heavy aluminum housing.

• Maximum voltage stability: The Hifonics 2.0 Farad capacitor with digital voltage display prevents voltage drops and protects the vehicle battery during hard bass hits.

• First-class signal paths: The 35mm² Stage2 OFC power cable set and the triple shielded RCA cable ensure absolutely clean and interference-free signal transmission.

• Specialized mounting accessories: The M8 ring set allows for proper and corrosion-protected integration of the capacitor into the power supply.

• Robust enclosure design: The stable wooden enclosure with front bass reflex tunnel is perfectly tuned to the three Iridium chassis.

Technical Data

Ground Zero Iridium GZIB 3.250SPL Enclosed Subwoofer:

• Configuration: 3x 25 cm (10″) GZIW 10XSPL Subwoofer

• Power: 1500W RMS / 2100W SPL Power

• Impedance: 1.4 Ohm connection impedance

• Construction: Reinforced paper cone (honeycomb structure), 50 mm copper voice coil, Xmax 34 mm

• Dimensions: 830 x 340 x 320/240 mm (W x H x D1/D2), net volume 60 l

DD Audio SS2000 Amplifier:

• RMS Power: 2000W @ 1 Ohm / 1400W @ 2 Ohm (9-16V)

• Filter: Subsonic 20-80 Hz, low pass 80-20,000 Hz

• Features: ZVL inputs, heavy aluminum construction, including Bass Remote Control

• Dimensions: 195 x 185 x 60 mm

Hifonics HFC2000 Capacitor:

• Rated Capacity: 2.0 Farads with blue LED voltage display

• Internal Resistance (ESR): 0.0015 Ohm @ 120 Hz

• Features: Remote connection, including load resistor and holder

• Dimensions: Ø 76 x 305 mm

Four Connect Stage2 Cable & Accessories:

• Power Kit: 35mm² OFC (5.2m power / 0.8m ground), 150A Mini-ANL Fuse, conduit

• Speaker Cable: 2m Stage2 2×2.5mm² OFC with silicone-based rubber insulation

• Connection Set: 2x ring terminals M8 (rhodium-plated) for 10-100mm² including Heat Shrink Tubing (red/black)

• RCA Cable: 5.5m triple shielded, rhodium-plated
