Geprüft Discovery 10F/4424G00

• Leistung 15/30 W, Impedanz 4 Ohm, Frequenzbereich 100-22kHz.
• Neodym-Magnet, Glasfaser-Membran, Empfindlichkeit 90 dB.
• Resonanzfrequenz 90Hz, Schwingspule 20mm, Masse 2,8g.
• More technical details

Discover the Discovery 10F/4424G00 from Scanspeak, a 4″ (10 cm) midrange driver known for its advanced technologies and top-notch craftsmanship. This midrange driver offers a very wide frequency range from 100 to 22,000 Hz, supported by a powerful neodymium magnet and a patented fiber glass diaphragm. With a compact size and an aluminum chassis, it is ideal for versatile applications. Additional features include a high sensitivity of 90 dB at 2.83 V, an SBR rubber surround, and a protective cap including grille. The resonance-free coating of the diaphragm significantly reduces vibrations.

Features

• Very wide frequency range
• Coated NRSC fiber glass membrane (patent)
• Compact size
• Neodymium magnet
• Aluminum chassis
• High sensitivity 90dB / 2.83V
• SBR rubber surround
• Copper cap on pole piece

Features

• 4″ (10cm) full-range speaker with fiber glass diaphragm and neodymium drive
• 4 Ohm impedance
• Power handling (rated/music) = 15/30 W
• Frequency range = 100-22000 Hz
• Resonance frequency fs = 90 Hz
• Reference sound pressure SPL = 89.76 dB (2.83V; 1m)
• DC resistance Re = 3.2 Ohm
• Force factor BL = 3.9 N/A
• Voice coil inductance L = 0.1 mH
• Effective diaphragm area Sd = 36 cm²
• Moving mass including air load mms = 2.8 g
• Equivalent volume Vas = 2 l
• Free air total quality Qts = 0.29 (Qms=3.2, Qes=0.32)
• Diameter of the voice coil = 20 mm
• Linear displacement x_lin= +/- 2.6 mm
• Patented neodymium magnet system
• Lossless linear suspension
• Magnet protection cap including grille before the pole core drilling
• Aluminum die-cast basket

Dimensions

• Installation diameter d = 78 mm
• Outer diameter d = 97.5 mm
• Installation depth (not milled) t = 44.65 mm
