Kostenfreie Lieferung Apocalypse ASA-550.4

• Power: 550 W RMS/channel at 1 ohm, 700 W bridged at 4 ohms.
• Impedance: Supports 1, 2 and 4 ohms, high audio precision.
• Frequency range: 10 Hz-20 kHz, wide filters for sound optimization.
• More technical details

The Deaf Bonce Apocalypse ASA-550.4 is a 4-Channel Amplifier of Class D technology. The power amounts to 550 Watts RMS per channel at an impedance of 1 Ohm and 350 Watts RMS at 2 Ohms. In bridged mode at 4 Ohms, 700 Watts RMS are achieved on two channels, while in regular 4-Ohm operation, 225 Watts RMS per channel are available. The device features adjustable high-pass filters from 10 Hz to 12,000 Hz and low-pass filters from 50 Hz to 12,000 Hz. The operating voltage ranges from 9 to 16 Volts with a signal-to-noise ratio of at least 90 dB. The construction has dimensions of 430 x 240 x 63.5 mm. The configuration can be set up as a 2-, 3-, or 4-channel system.

Features

• 4-Channel Amplifier
• Amplifier Class: Class D
• Power at 1 Ohm RMS: 550 W x 4
• Power at 2 Ohm RMS: 350 W x 4
• Power at 4 Ohm bridged RMS: 700 W x 2
• Power at 4 Ohm RMS: 225 W x 4
• Dimensions: 430 x 240 x 63.5 mm
• Robust housing

Technical Specifications

• Frequency range: 10–20,000 Hz
• High-pass filter: 10–1200 / 100–12000 Hz
• Low-pass filter: 50–1200 / 500–12000 Hz
• Operating voltage: 9 – 16 V
• Recommended power and ground cable: 0 Ga
• Signal noise: ≥ 90 dB
