Markenware Carbon Set 10/130

• CARBON10 BR subwoofer, 350/250 watts power, impedance 4 ohms.
• CARBON-200.4 amplifier, 4x 50(80) WRMS, RCA high level inputs.
• CARBON 130 system, tweeter, woofer, impedance 4 ohms.
• More technical details

The Carbon Set 10/130 from Audio System is a Subwoofer Complete Set from the CARBON SERIES. It consists of the CARBON10 BR Subwoofer in a 28-liter bass reflex enclosure, the 4-Channel Amplifier Carbon-200.4, and the component system Carbon 130 including the Crossover FW CARBON. The Subwoofer operates with an impedance of 4 Ohms and a power handling of 350/250 Watts. The amplifier features variable high-pass and low-pass filters, RCA high-level inputs with automatic turn-on, and an input sensitivity of 0.2 to 8 Volts. The component system Carbon 130 includes the Tweeter CARBON TW 24 and the Woofer AC 130. The system elements are complemented by the cable set PCS6 and the Z-EVO 5.0M ECO.

Features

• Subwoofer Complete Set
• CARBON10 BR Subwoofer in a 28-liter bass reflex enclosure
• Carbon-200.4 4-Channel Amplifier
• Carbon 130 component system with CARBON TW 24 Tweeter and AC 130 Woofer
• FW CARBON Crossover
• Including PCS6 and Z-EVO 5.0M ECO
• RCA high-level input with automatic turn-on
• Variable, switchable HP and LP filters
• Impedance: 4 Ohms

Technical Data

• Subwoofer power: 350 Watts maximum power
• Subwoofer power: 250 Watts RMS
• Amplifier power: 4x 50 WRMS at 4 Ohms
• Amplifier power: 4x 80 WRMS at 2 Ohms
• Amplifier power: 2x 160 WRMS Mono at 4 Ohms
• Component system power: 2x 110 Watts maximum power
• Component system power: 2x 70 Watts RMS
• Subwoofer enclosure dimensions: 500 mm x 310 mm x 170 mm / 283 mm
• Amplifier dimensions: 303 mm x 58 mm x 220 mm
• Woofer mounting depth: 53 mm
• Woofer mounting diameter: 114 mm
• Tweeter outer dimension: 128 mm
• Woofer outer dimension: 149 mm
• Input sensitivity: 0.2 – 8 Volts
