Neu Im Sortiment AE30

• 30 W maximum power, 3.6 Ohm impedance, 88 dB sensitivity.
• Frequency range of 100 Hz, conical paper with special rubber edge.
• Qms 3.9, Qes 0.53, Qts 0.46, aluminum construction.
• More technical details

The AE30 from Audio System Italy is a top-class 3″ (8cm) midrange speaker. Made with cone paper and a special rubber surround plus aluminum, it stands out due to its outstanding technical specifications. With a maximum power of 30W and a frequency range of 100 Hz, the AE30 delivers top-notch performance. Another feature is its impressive sensitivity of 88 dB, enhanced by integrated technical specifications such as Qms of 3.9, Qes of 0.53, and Qts of 0.46. This midrange speaker is not only powerful but also compact, weighing only 0.235 KG.

Technical Data

• Cone paper: Special rubber edge + Aluminum
• DC Impedance: 3.6
• Maximum power: 30 W
• Frequency range: 100 Hz
• Sensitivity 1W/1M: 88 dB
• Qms: 3.9
• Qes: 0.53
• Qts: 0.46
• Mms: 2.9 G
• Vas: 0.21 L
• Weight: 0.235 KG
• Mounting depth: 42.0 MM
• Installation diameter: 86.0 MM
