Neue Kollektion Punch P1000X5

• 75W x 4 + 150W x 1 @ 4-Ohm, 125W x 4 + 300W x 1 @ 2-Ohm.
• 5-channel amplifier, Class A/B + BD, Punch EQ.
• Short circuit protection, overcurrent protection, infrasound filter.
• More technical details

Rockford Fosgate Punch P1000X5, 5-Channel Amplifier with Class A/B + Class BD Sub Circuit. RMS Power: 75 Watts x 4 at 4 Ohms for Front/Rear and 150 Watts x 1 at 4 Ohms on the Sub Channel; 125 Watts x 4 at 2 Ohms for Front/Rear and 300 Watts x 1 at 2 Ohms on the Sub Channel; up to 500 Watts x 1 at 1 Ohm on the Sub Channel. Dynamic Power: 115 Watts x 4 + 299 Watts x 1 at 4 Ohms, 190 Watts x 4 + 540 Watts x 1 at 2 Ohms, and 863 Watts x 1 at 1 Ohm on the Sub Channel. High-level input with Auto Turn-On, C.L.E.A.N. setting, and built-in Punch-EQ with up to +18 dB at 45 Hz. 12 dB/Octave Butterworth Crossover, infrasonic filter, and 2/4-channel input switch. Short circuit and overcurrent protection, stealth control panel on top, mute on power-up, and cast aluminum heat sink.

Features

• 5-Channel Amplifier
• High-level input with Auto Turn-On circuit
• C.L.E.A.N. setting
• Built-in Punch-EQ with +18 dB boost at 45 Hz
• 12 dB/Octave Butterworth Crossover
• Optional Punch-Level-Control remote PLC2 with input clip indicator
• Mute on power-up
• Stealth control panel on top
• Short circuit protection
• Overcurrent protection
• Infrasonic filter
• 2/4-channel input switch
• Cast aluminum heat sink

Technical Specifications

• Bridgeable: Yes front/rear channels
• RMS Power @ 4 Ohms Front/Rear: 75 Watts x 4
• RMS Power @ 4 Ohms Sub: 150 Watts x 1
• RMS Power @ 2 Ohms Front/Rear: 125 Watts x 4
• RMS Power @ 2 Ohms Sub: 300 Watts x 1
• RMS Power @ 1 Ohm Sub: 500 Watts x 1
• Dynamic Power @ 4 Ohms Front/Rear: 115 Watts x 4
• Dynamic Power @ 4 Ohms Sub: 299 Watts x 1
• Dynamic Power @ 2 Ohms Front/Rear: 190 Watts x 4
• Dynamic Power @ 2 Ohms Sub: 540 Watts x 1
• Dynamic Power @ 1 Ohm Sub: 863 Watts x 1
• Frequency Response Front/Rear: 20 Hz – 20 kHz +/-3 dB
• Frequency Response Sub: 20 Hz – 500 Hz +/-3 dB
• Input Sensitivity: 150 mV – 12 V
• Circuit Topology: Class A/B + Class BD Sub
• Efficiency Front/Rear average: 66%
• Efficiency Sub Channel average: 80%
• Total Harmonic Distortion THD+Noise: less than 1.0%
• Signal Input: Hi/Low-Level Input
• Input Switch: 2/4-channel input
• High/Low Level: 3 RCA pairs
• Sub: Front/Sub input switch
• Sub Tone Control: 0 dB to +18 dB @ 45 Hz
• Front: 50 Hz – 250 Hz High-pass @ 12 dB/Octave
• Rear: 50 Hz – 250 Hz High-pass @ 12 dB/Octave
• Sub: 50 Hz – 250 Hz Low-pass
• Sub: 28 Hz Infrasonic filter @ 12 dB/Octave
• Remote Controls: Optional Punch-Level Control PLC2 ready
• Optical Indicators: Power/Protection/Thermal LED
• Cable Diameter: 20mm²
• Speaker Cable Diameter: 6mm²
• Cooling: Convection
• Operating Voltage: 9 – 16 VDC
• Recommended Fuse: 150 A
• Average Current Draw 13.8 V Music: 75 A
• Max Current Draw 13.8 V Sine: 150 A
• Dimensions H x W x D: 6.05 x 19.71 x 38.18 cm
• Shipping Weight: 6.93 Kg
