Nur Heute MWS822

• Power 250 watts RMS, maximum 500 watts, impedance 2 + 2 ohms.
• 50 mm voice coil, robust steel construction, 1.13 kg magnet.
• Resonance frequency 39.7 Hz, SPL 86 dB, Xmax +/15 mm.
• More technical details

The Musway MWS822 is an 8-inch (20 cm) Subwoofer with 250 Watts RMS and 500 Watts maximum. It features an impedance of 2 + 2 Ohms, a 50 mm voice coil, and a robust steel basket. A magnet weighing 1.13 kg and a sound pressure level of 86 dB/2.83 V/1 m are specified. The resonance frequency is at 39.7 Hz, the total Q factor is 0.575, and the equivalent volume is 10.9 L. The maximum linear excursion is +/- 15 mm, the installation depth is 78 mm, and the cutout diameter is 182 mm.

Features

• 8-inch (20 cm) Subwoofer
• 250 Watts RMS
• 500 Watts maximum
• Impedance 2 + 2 Ohms
• 50 mm voice coil
• Robust steel basket
• Magnet 1.13 kg (40 ounces)
• Sound pressure level 86 dB/2.83 V/1 m
• Xmax +/- 15 mm
• Installation depth 78 mm
• Cutout diameter 182 mm

Technical Specifications

• Resonance frequency (Fs) 39.7 Hz
• Total Q factor (Qts) 0.575
• Equivalent volume (VAS) 10.9 L
