Preiswert Apocalypse AP-M81 SE

• Power max. 340W, RMS 170W, impedance 4 Ohm, SPL 95.1 dB.
• Frequency range 110-10000 Hz, ferrite magnet, BL 8.15, Fs 110 Hz.
• Voice coil 1.50 inches, diaphragm made of pressed paper, Qts 0.66.
• More technical details

Apocalypse AP-M81 SE is an 8 inch (20 cm) mid-bass driver from Deaf Bonce. The frequency range is 110-10000 Hz and the sensitivity is 95.10 dB. The RMS power is 170 W. The maximum power is 340 W. The construction includes a steel basket, a pressed paper diaphragm, a ferrite magnet, and a 38.1 mm voice coil with copper-coated aluminum wire. The impedance is 4 Ohms. The dimensions include a mounting depth of 87.5 mm, a cutout size of 186.0 mm, and an outer diameter of 200 mm; the gross weight is 6.27 kg. Technical specifications: Fs 110 Hz, Qts 0.66, BL 8.15, and Vas 15.21 l.

Features

• 8 inch (20 cm) mid-bass driver
• Manufacturer: Deaf Bonce
• Model: Deaf Bonce AP-M81SE
• Impedance: 4 Ohms
• RMS power: 170 W
• Maximum power: 340 W
• SPL: 95.10 dB
• Frequency range: 110-10000 Hz
• Diaphragm material: Pressed paper
• Magnet material: Ferrite
• Voice coil: 38.1 mm
• Voice coil wire: Copper-coated aluminum
• Basket: Steel
• Mounting depth: 87.5 mm
• Cutout size: 186.0 mm
• Outer diameter: 200 mm
• Gross weight: 6.27 kg

Technical Data

• Fs: 110.00 Hz
• Qts: 0.66
• BL: 8.15
• Vas: 15.21 l
