Preiswert DEFINITION 4

• Power at 4 ohms: 105 watts, bridged 320 watts, flexibility.
• Frequency response: 10 Hz to 40 kHz, RCA impedance: 5 kOhm.
• Signal-to-noise ratio: 90 dB, attenuation factor: over 100.
• More technical details

DEFINIO 4 by Xcelsus is a 4-Channel Amplifier in Full Range Digital design. The frequency response ranges from 10 Hz to 40 kHz, the signal-to-noise ratio (A-weighted) is 90 dB, and the damping factor is >100. The RMS power is 105 Watts at 4 Ohms, 165 Watts at 2 Ohms, and bridged 320 Watts at 4 Ohms. Additionally, it features adjustable high-pass and low-pass filters from 50 to 500 Hz, an input sensitivity of 0.2 to 6 V, and an input impedance of 5 kOhm. The total harmonic distortion (THD) is <0.02 % at 5 W and 1 kHz. The power supply operates at 12 Volts; the current consumption is 0.7 A (0.35 A) at idle, with a maximum of 60 A, and the external fuse is rated at 60 A. The dimensions are 418 x 104 x 270 mm.

Features

• 4-Channel Amplifier
• Amplifier Class: Full Range Digital
• Number of Channels: 4
• RMS Power at 4 Ohms: 105 Watts
• RMS Power at 2 Ohms: 165 Watts
• Bridged RMS Power at 4 Ohms: 320 Watts
• Adjustable High-Pass Filter: 50–500 Hz
• Adjustable Low-Pass Filter: 50–500 Hz

Technical Specifications

• Frequency Response: 10 Hz – 40 kHz
• Signal-to-Noise Ratio (A-weighted): 90 dB
• Damping Factor: >100
• Total Harmonic Distortion (THD) @ 5 W, 1 kHz: <0.02 %
• Input Impedance (RCA): 5 kOhm
• Input Sensitivity: 0.2–6 V
• Idle Current Consumption: 0.7 A (0.35 A)
• Maximum Current Consumption: 60 A
• External Fuse: 60 A
• Power Supply: 12 Volts
• Dimensions: 418 x 104 x 270 mm
