Prima APK 570 Direkt Vom Hersteller

• Peak power 300W, impedance 4 Ohm, frequency response 55-20kHz.
• Compact crossovers, tweeter 26mm, woofer 570mm.
• Large voice coil, high power handling, fast connection.
• More technical details

Audison Prima APK 570 is a 5 x 7 inch Speaker Set with AP 570 Woofer, AP 1 Tweeter, and ultra-compact APCX TW 570 Crossovers with HP 6 dB/Oct at 3 kHz. The power handling is 100 W continuous and 300 W peak, the impedance is 4 Ohm, and the frequency response is 55 Hz to 20 kHz. The Woofer uses a 32 mm copper voice coil, a water-repellent treated paper cone with FEM-developed profile and Klippel optimization, a low installation depth, and a Triple Wave surround. The basket is compact, with abrasion and scratch-resistant coating, the motor is secured with damping epoxy glue, and there are high-current quick connections with double contact. The mechanical shutdown of the cone dust cap system allows operation without a filter. The AP 1 Tweeter has a 26 mm diaphragm with wide roll surround, an acoustic lens for the range of 10 kHz to 13 kHz, and a 20 mm voice coil. The crossover features a damping switch with 0 dB or +2 dB and comes with quick connections. The SPL of the Woofer is 93.5 dB.

Features

• 5 x 7 inch Speaker Set
• Included: AP 570 Woofer, AP 1 Tweeter, APCX TW 570 Crossovers
• Power Handling Continuous 100 W
• Power Handling Peak 300 W
• Impedance 4 Ohm
• Frequency Response 55 Hz to 20 kHz
• Crossover HP 6 dB/Oct at 3 kHz, ultra-compact
• Damping switch on the crossover 0 dB or +2 dB
• AP 1 Tweeter with 26 mm diaphragm, wide roll surround, and acoustic lens 10 kHz to 13 kHz
• AP 1 Tweeter voice coil 20 mm
• AP 570 Woofer with 32 mm copper voice coil
• Water-repellent treated paper cone, FEM profile, Klippel optimized
• Low installation depth
• Triple Wave Surround
• Compact basket, abrasion and scratch-resistant coating
• Motor secured with damping epoxy glue
• High-current quick connection with double contact and direct connection to the Tweeter
• Mechanical shutdown of the cone dust cap system; operation without filter possible

Technical Specifications

• Woofer Size 570 mm
• Tweeter Size 26 mm
• Voice Coil Diameter Woofer 32 mm
• Voice Coil Diameter Tweeter 20 mm
• Crossover Type HP 6 dB/Oct at 3 kHz
• Magnet Size Woofer 85 x 40 x 15
• Power Handling Peak 300 W
• Power Handling Continuous 100 W
• Impedance 4 Ohm
• Frequency Response 55 Hz to 20 kHz
• Woofer Cone Diameter 139 mm
• Xmax Woofer 2.5 mm
• Re Woofer 3.1 Ohm
• Fs Woofer 70 Hz
• Le Woofer 0.23 mH @ 1 kHz
• Vas Woofer 10.5 l
• Mms Woofer 14.5 g
• Cms Woofer 0.32
• Bxl Woofer 4.6
• Qts Woofer 0.85
• Qms Woofer 6.5
• Qes Tweeter 2.78
• SPL Woofer 93.5 dB
• Weight Woofer 0.88 kg
• Weight Tweeter 0.04 kg
