Rage 3MR Rabatt

• 50 watts RMS power, 4 ohms impedance, 81.2 dB sensitivity.
• 3″ midrange driver, frequency range from 200 Hz to 12 KHz.
• Neodymium magnet, resonance frequency at 190 Hz, 4.9 ohm DC resistance.
• More technical details

The Rage 3MR is a 3-inch midrange driver from B2 Audio. This model is the perfect link between horn tweeters and high-efficiency mid-bass drivers of the Rage series. It enables the construction of an SPL-capable front system with excellent sound performance. Furthermore, the Rage 3MR impresses with its shallow mounting depth of only ~1″ / 27 mm and a cutout of 2.51″ / 63.8 mm. Therefore, it can be easily installed in almost any A-pillar or door. With its technical features and a weight of only 6.9 g, it proves to be a powerful yet lightweight device.

Technical Features

• 3-inch midrange driver including grille
• Power handling: 50 Watt RMS
• Power handling: 100 Watt MAX
• Frequency range: 200 Hz ~ 12 KHz
• Sensitivity: 81.2 dB
• Nominal impedance: 4 Ohm
• DC resistance (RE): 4.9 Ohm
• Resonant frequency (FS): 190 Hz
• QMS: 5.04
• QES: 1.29
• QTS: 1.03
• CMS: 81 um/N
• Weight: 6.9 g
• Voice coil diameter: 1″
• BL: 5.9
• Magnet type: Neodymium

Dimensions

• Outer diameter: 87.0 mm
• Mounting depth: 39.5 mm
• Mounting diameter: 69.0 mm
• Bolt circle diameter: 78 mm

Enclosure Recommendation

• 0.4l sealed
