RVC82MT Finale Aktion

• 6.09 mm SONY CMOS Sensor, focal length f 1.8, 170° viewing angle.
• Video output: 1.0 Vp-p, 75 Ohm, signal-to-noise ratio > 48 dB.
• Power consumption 70 mA @12V, protection class IP69K certificate.
• More technical details

The RVC82MT camera accessory from Zenec is a compact, high-resolution universal rearview camera. Equipped with a 6.09 mm SONY IMX225LQR CMOS sensor and a focal length of f 1.8, it offers excellent image quality with a native sensor resolution of 1305 (H) x 977 (V) pixels. The robust aluminum die-cast housing and IP69K certification ensure durability and protection against environmental influences. With a diagonal viewing angle of 170°, automatic white balance, and a light sensitivity of 0.3 Lux, it is ideally suited for use day and night. The 10 m long system cable and the easy mounting using a hollow screw make installation straightforward. This camera adapts to your needs thanks to the vertical image cropping adjustment.

Specifications

• Camera system: 6.09 mm SONY IMX225LQR CMOS Sensor
• Focal length lens: f 1.8
• TV System: NTSC / 30 fps
• Viewing angle: 170° (D) x 135° (H) x 90° (V)
• Native Sensor Resolution: 1305 (H) x 977 (V) pixels
• Resolution output signal: > 420 TV lines
• Signal-to-noise ratio: > 48 dB
• Light sensitivity: 0.3 Lux
• Video Output: 1.0 Vp-p, 75 Ohm CVBS
• White balance: Automatic
• Exposure Compensation: Automatic
• Gamma Correction: 0.45
• Brightness adjustment: Automatic
• Synchronization: Automatic
• Power supply: DC 6 – 24 V
• Power consumption: 70 mA @12 VDC, ≤ 480 mW
• Protection class: IP69K
• Operating temperature: -30° C ~ +75°C, RH 95% Max.
• Dimensions (HxWxD): 44 x 23 x 29 mm

Main features

• Compact, high-resolution universal rearview camera
• Robust camera housing made of aluminum die-cast
• Cam sensor with a 170° diagonal viewing angle for a wide monitoring area behind the vehicle
• Vertical image cropping adjustment via rotatable sensor roller, 0° to 70° upwards / 0° to 70° downwards
• High-sensitivity CMOS sensor with 0.3 Lux light sensitivity for good night vision
• 10 m long separable system cable with mini 4-PIN connectors
• Required cable entry hole: 6.1 mm, simple mounting via M6 hollow screw.
• IP69K certified
