Saisonangebot Apocalypse Atom 1600.1 PRO

• RMS power of 1600 W @ 1 Ohm, frequency range 10-250 Hz.
• Low-pass filter, high-pass filter, damping factor ≥ 140.
• Operating voltage 9 15 V, dimensions 140.0 x 230.0 x 54.0 mm.
• More technical details

The Apocalypse Atom 1600.1 PRO is a 1-Channel Amplifier from Deaf Bonce in Class D. The frequency range is 10–250 Hz, and the minimum load impedance per channel is 1 Ohm. The RMS power ratings are specified for 1, 2, and 4 Ohm, additionally for 1 Ohm at 12 V. It features a low-pass filter from 40–250 Hz and a high-pass filter from 10–50 Hz, complemented by a Crossover with 12 dB/Oct. and a bass adjustment of 35–90 Hz. The input sensitivity is 0.2–6 V, the damping factor is ≥ 140, and the signal-to-noise ratio is ≥ 93 dB. The operating voltage is 9–15 V; connections are designed as 25 mm² power and 6 mm² speaker terminals, and the housing measures 140 x 230 x 54 mm. Weight with packaging is 2.36 kg; accessories include the amplifier, remote control, mounting kit, manual, and warranty card.

Features

• 1-Channel Amplifier
• Class D
• RMS Power @ 1 Ohm (14.4 V): 1600 W
• RMS Power @ 1 Ohm (12 V): 1430 W
• RMS Power @ 2 Ohm (14.4 V): 1010 W
• RMS Power @ 4 Ohm (14.4 V): 550 W
• Minimum load impedance per channel: 1 Ohm
• Input sensitivity: 0.2–6 V
• Low-pass filter: 40–250 Hz
• High-pass filter: 10–50 Hz
• Crossover: 12 dB/Oct.
• Bass adjustment: 35–90 Hz
• Power connections: 25 mm²
• Speaker connections: 6 mm²
• Dimensions (LxWxH): 140 x 230 x 54 mm
• Weight with packaging: 2.36 kg
• Accessories: amplifier, remote control, mounting kit, manual, warranty card

Technical Specifications

• Frequency range: 10–250 Hz
• Operating voltage: 9–15 V
• Damping factor: ≥ 140
• Signal-to-noise ratio: ≥ 93 dB
• Model: Atom 1600.1 PRO
