Schnäppchen ATC130S

• Frequency response 80Hz 25kHz, Impedance 4 Ohm, Sensitivity 88 dB.
• Powerful 70 Wrms, 25 mm tweeter with neodymium magnet.
• Precision stamped steel basket, Strontium Ferrite, polypropylene cone.
• More technical details

The ATC130S speaker set from Axton is a 5-inch speaker system that impresses with precision-engineered steel baskets and strontium ferrite magnets. The low-resonance polypropylene cone and the linear-working surround made of NBR nitrile rubber ensure clear sound. The 25 mm tweeter with fabric dome and neodymium magnet with ferrofluid cooling offers clear high-frequency reproduction. With a frequency response from 80Hz to 25 kHz and a nominal impedance of 4 ohms, the system convinces on a technical level. The ATC130S comes with a space-saving crossover and offers useful mounting adapters for various installation options.

Highlights

Woofer/Midrange

• Precision-engineered steel basket
• Strontium ferrite magnet
• Low-resonance polypropylene cone
• Linear-working surround made of NBR nitrile rubber
• Ventilated NOMEX centering spider
• Voice coil on polyimide former
• Hard gold-plated, corrosion-resistant connectors
• Speaker grille included

Tweeter

• 25 mm tweeter with fabric dome
• Diffuser for optimal spatial imaging
• Powerful neodymium magnet with ferrofluid cooling
• Includes mounting adapters for surface and flush mounting

Crossover

• Space-saving 6 dB/oct. inline crossover
• Level attenuation for tweeter -3 dB/0 dB

Specifications

• Frequency response 80Hz – 25 kHz
• Nominal impedance 4 ohms
• Sensitivity (1 W/1 m) 88 dB
• Rated power handling 70 Wrms
• Mounting diameter 116 mm
• Mounting depth 43 mm
