Schnäppchen Quantum Q-FOURv3 24V

• 4 x 100/120 Watt RMS @ 4/2 Ω, compact with 150 x 50 x 220 mm.
• Efficiency up to 84%, constant power, automatic switching on.
• HPF 20-4000 Hz, Bass Boost 0-12 dB, LPF 50-4000 Hz.
• More technical details

The Quantum Q-FOURv3 24V from ESX is a 4-Channel Class D Compact Digital Amplifier from the Quantum Q compact class. The device is designed for operation in 12-volt and 24-volt systems and features Constant Power technology. The construction includes a heavy cast heat sink and an acrylic cover in piano finish. With dimensions of 150 x 50 x 220 mm, the amplifier has a compact design. The equipment includes high-level inputs with Error Protection System (EPS), an automatic turn-on function, and start/stop compatibility. For sound adjustment, a bass boost of 0 to 12 dB and HPF and LPF filter settings are available.

Features

• Product Type: 4-Channel Amplifier
• Class D Technology
• Constant Power Technology
• Heavy Cast Heat Sink
• High-Level Inputs with Error Protection System (EPS)
• Automatic Turn-On Function
• Start/Stop Ready
• Acrylic Cover in Piano Finish
• Dimensions: 150 x 50 x 220 mm

Technical Specifications

• Power: 4 x 100 Watts RMS at 4 Ohms
• Power: 4 x 120 Watts RMS at 2 Ohms
• Power: 2 x 200 Watts RMS at 4 Ohms bridged
• Efficiency: up to 84 percent
• HPF: 20-4000 Hz (CH1/2)
• HPF: 10-500 Hz (CH3/4)
• LPF: 50-4000 Hz (CH3/4)
• Bass Boost: 0-12 dB
• Dupe Mode: CH3/4 > CH1/2
