Solange Der Vorrat Reicht HED Series H7TAK

• Power: 35 W RMS, 300 W MAX, 4 Ohm impedance.
• Sensitivity: 97 dB, Frequency response: 3,500 20,000 Hz.
• Materials: steel frame, PEI tweeter, robust construction.
• More technical details

The Cerwin Vega HED Series H7TAK is a 25 mm Silk Dome Tweeter designed for integration into 2-, 3-, or 4-way systems. The technical construction is based on a stamped steel frame and a symmetrical PEI high-frequency speaker made of black polypropylene. The system has an impedance of 4 Ohms and a sensitivity of 97 dB. The frequency response covers the range from 3,500 to 20,000 Hz. An external Crossover is included. The installation can be done as surface, angle, or flush mounting.

Features

• Dome Tweeter
• 25 mm Silk Dome Tweeter Kit
• Symmetrical PEI high-frequency speaker construction
• Stamped steel frame
• Reinforced cone made of black polypropylene
• Rated power: 35 Watts each
• Peak power: 300 Watts each
• 4 Ohm impedance
• External Crossover included

Technical Specifications

• Sensitivity: 97 dB
• Frequency response: 3,500 – 20,000 Hz
• Mounting depth: 20 mm
• Diameter: 51 mm
• Cutout diameter: 47 mm
• Size compatibility: 89 mm to 102 x 254 mm
