Solange Der Vorrat Reicht Xtreme EDX5000.1D-E2

• 1-channel amplifier, 92% efficiency, 50mm² connections.
• MOSFET output, bass boost, Korean design.
• 11000W max, 10Hz-350Hz, Ultra Class D.
• More technical details

The Xtreme EDX5000.1D-E2 is a 1-Channel Amplifier from EDGE as an Ultra Class D Monoblock with up to 92% efficiency. It features two 50mm² power connections and a MOSFET output stage. The parametric bass boost can be adjusted up to +12 dB between 30 Hz and 90 Hz. A level remote control is included. Notable features include the Korean design (bridgeable) and full EMI and CE certification. RMS power: 1 x 1580 Watts at 4 Ohm (14.4 V, 1% THD), 1 x 3000 Watts at 2 Ohm (14.4 V, 1% THD), and 1 x 5500 Watts at 1 Ohm (14.4 V, 1% THD). Additionally, 1 x 5700 Watts at 1 Ohm at 16 V (1% THD) and 1 x 5800 Watts at 1 Ohm at 18 V (1% THD). Maximum power 11000 Watts. Frequency response 10 Hz to 350 Hz, Crossover LP/Subsonic with 10 Hz to 250 Hz, input sensitivity 200 mV to 8 V.

Features

• 1-Channel Amplifier
• Ultra Class D Monoblock with up to 92% efficiency
• Two 50mm² power connections
• MOSFET output stage
• Parametric bass boost up to +12 dB (30 Hz – 90 Hz)
• Korean design (bridgeable)
• Includes level remote control
• Full EMI and CE certification
• Manufacturer: EDGE

Technical Specifications

• Model: EDX5000.1D-E2
• Configuration: Monoblock
• Topology: Ultra Class D
• RMS at 4 Ohm (14.4 V, 1% THD): 1 x 1580 Watts
• RMS at 2 Ohm (14.4 V, 1% THD): 1 x 3000 Watts
• RMS at 1 Ohm (14.4 V, 1% THD): 1 x 5500 Watts
• RMS at 1 Ohm (16 V, 1% THD): 1 x 5700 Watts
• RMS at 1 Ohm (18 V, 1% THD): 1 x 5800 Watts
• Maximum power: 11000 Watts
• Frequency response: 10 Hz – 350 Hz
• Crossover: LP / Subsonic
• Crossover range: 10 Hz – 250 Hz
• Input sensitivity: 200 mV – 8 V
