Voice II AVBX 10 D4 II Jetzt Kaufen

• Impedance: 4+4 Ohm Dual Voice Coil, Power: 550 W.
• Frequency Response: 25 Hz to 400 Hz, Resonance: 36 Hz (Fs).
• Max. Excursion: 16.8 mm, Moving Mass: 250 g, BL: 11.2 Tm.
• More technical details

The Voce II AVBX 10 D4 II from Audison is a 10-inch enclosure Subwoofer that offers flexibility in installation with its multiple impedance options of 4+4 Ohm with dual voice coil. The Subwoofer impresses with a constant power handling of 550 W and a peak power of 1100 W. With a frequency response of 25 Hz to 400 Hz, it produces deep and powerful bass. The combination of an aluminum basket, a polypropylene diaphragm with mica injection, and a rubber surround ensures stability and durability. The highly compressed ferrite magnet maximizes efficiency, while the compact design with a net volume of 0.6 liters saves space.

Technical Specifications

• Nominal Diameter: 250 mm (10 inch) Subwoofer Chassis
• Impedance: 4+4 Ohm Dual Voice Coil
• Power Handling: 550 W Continuous (1100 W Peak)
• Frequency Response: 25 Hz to 400 Hz
• Voice Coil: 37 mm Winding Height from CCAW on Fiberglass Carrier
• Magnet Material: Highly Compressed Ferrite
• Material Mix: Aluminum Basket, Polypropylene Diaphragm with Mica Injection and Rubber Surround
• Net Volume: 0.6 liters Driver Displacement

Electroacoustic Parameters

• Resonance Frequency (Fs): 36 Hz
• Equivalent Volume (Vas): 14.8 liters
• Maximum Stroke (Xmax): 16.8 mm (Xmech 20 mm)
• Moving Mass (Mms): 250 g
• Total Quality (Qts): 0.7 (Qms 5.62)
• DC Resistance (Re): 1.82 Ohm
• Drive Factor (BL): 11.2 T•m
• Effective Diaphragm Area (D): 368 cm²

Dimensions & Installation

• Outer Length (A): 531 mm
• Outer Width (B): 361 mm
• Enclosure Depth (C): 160 mm
• Overhang (D): 32.9 mm
• Inner Depth (C1): 118 mm
